Journal of Peking University (Health Sciences) ›› 2025, Vol. 57 ›› Issue (4): 662-665. doi: 10.19723/j.issn.1671-167X.2025.04.005

Previous Articles     Next Articles

Preliminary application of domestic single-port serpentine arm robotic surgical system in children's pyeloplasty

Zonghan LI, Yangyue HUANG, Ning LI, Minglei LI, Hongcheng SONG, Weiping ZHANG, Chao LIU*()

  1. Department of Urology, Beijing Children's Hospital, Capital Medical University, National Center for Children's Health, Beijing 100045, China
  • Received:2025-01-22 Online:2025-08-18 Published:2025-08-02
  • Contact: Chao LIU
  • Supported by:
    the Science and Technology Planning Program of Beijing Municipal Science & Technology Commission and Administrative Commission of Zhongguancun Science Park(Z231100004823034)

RICH HTML



Abstract:

Objective: To investigate the safety and feasibility of the domestic single-port serpentine-arm robotic surgical system for pyeloplasty in children with congenital ureteropelvic junction obstruction (UPJO). Methods: Data of UPJO patients who underwent pyeloplasty using a domestic single-port serpentine-arm robotic surgical system (Beijing Surgerii Robotics Co., Ltd.) in Beijing Children's Hospital from November 2023 to February 2024 were retrospectively collected. The patients who were not receiving surgical treatment for the first time, had hydronephrosis caused by other reasons (such as ureterovesical junction obstruction, posterior urethral valve, urinary tract stones, vesicoureteral reflux, ureterocele, etc.), had other urinary tract malformations (such as duplicated kidneys, congenital renal dysplasia, etc.), had severe atrophy of the affected kidney, severe urinary tract infection or severe renal insufficiency were excluded. All the surgeries were performed through the umbilicus and abdominal cavity, and the operation time, number of intraoperative incisions, incision size, intraoperative blood loss, and peri-operative complications were recorded. Statistical analysis was performed to compare changes in the anteroposterior pelvic diameter (APD) and renal cortical thickness before surgery and 6 months postoperatively. Results: A total of 10 patients were included (8 males and 2 females), with an average age of (10.20±3.12) years. Nine patients were on the left side and one patient was on the right side. The average height was (142.0±17.8) cm and the average weight was (37.6±17.9) kg. All the patients underwent surgery using the domestic single-port robotic surgery system, and no patient was converted to open pyeloplasty. The total operation time was (237±96) min, and the operation time on the operating table was (162.0±69.3) min. The intraoperative blood loss was 5.00 (2.25, 5.00) mL. No complications, such as bleeding, urine extravasation, fever, and poor wound healing occurred during the perioperative period. Compared with the preoperative measurements, the APD was significantly shortened postoperatively (P=0.005), and the renal cortical thickness significantly increased (P=0.011). Conclusion: The domestic single-port serpentine arm robotic surgical system is safe and feasible for UPJO pyeloplasty in children, with good surgical results, and can be promoted and applied in most domestic medical centers.

Key words: Single-port surgical robot, Robotic surgical procedures, Hydronephrosis, Pyeloplasty, Children

CLC Number:

  • R699.2

Figure 1

Key intraoperative steps and corresponding images (take a patient with left hydronephrosis as an example) A, robotic arm configuration: Arm ① (bottom) is the needle holder, Arm ② (left) is the bipolar forceps, Arm ④ (right) is the monopolar curved scissors; B, free the left descending colon mesentery; C, dissection of the ureteropelvic junction (UPJ); D, renal pelvis trimming; E, the ureter is incised distally from the stricture; F, continuous suturing of the posterior wall between the ureter and renal pelvis; G, placement of a double-J stent; H, continuous suturing of the anterior wall between the ureter and renal pelvis."

1
Radmayr C, Bogaert G, Dogan HS, et al. EAU guidelines on paediatric urology [EB/OL]. [2025-01-10]. https://uroweb.org/guidelines/paediatric-urology.
2
Szavay P , Zundel S . Surgery of uretero-pelvic junction obstruction (UPJO)[J]. Semin Pediatr Surg, 2021, 30 (4): 151083.
3
Gatti JM , Amstutz SP , Bowlin PR , et al. Laparoscopic vs open pyeloplasty in children: Results of a randomized, prospective, controlled trial[J]. J Urol, 2017, 197 (3 Pt 1): 792- 797.
4
Piaggio LA , Corbetta JP , Weller S , et al. Comparative, prospective, case-control study of open versus laparoscopic pyeloplasty in children with ureteropelvic junction obstruction: Long-term results[J]. Front Pediatr, 2017, 5, 10.
5
Silay MS , Danacioglu O , Ozel K , et al. Laparoscopy versus robo-tic-assisted pyeloplasty in children: Preliminary results of a pilot prospective randomized controlled trial[J]. World J Urol, 2020, 38 (8): 1841- 1848.
6
Ren C , Sun DW . Robot-assisted single-port laparoscopic bilateral ovarian cystectomy using the Shurui® system: A case report[J]. Int Surg, 2022, 3, 9- 13.
7
Peng D , Jing T , Yao X , et al. Preliminary experience of partial nephrectomy through a new single-port surgical robot system[J]. J Endourol, 2023, 37 (5): 535- 541.
8
Guo Z , Shi Y , Song Z , et al. Single-incision robotic assisted surgery: A nonrandomized cohort pilot study on a novel surgical platform in colorectal surgery[J]. Int J Surg, 2023, 109 (11): 3417- 3429.
9
Gettman MT , Neururer R , Bartsch G , et al. Anderson-Hynes dismembered pyeloplasty performed using the da Vinci robotic system[J]. Urology, 2002, 60 (3): 509- 513.
10
Fuchs ME , DaJusta DG . Robotics in pediatric urology[J]. Int Braz J Urol, 2020, 46 (3): 322- 327.
11
Sun L , Zhao D , Shen Y , et al. Laparoscopic versus robot-assisted pyeloplasty in infants and young children[J]. Asian J Surg, 2023, 46 (2): 868- 873.
12
Katagiri H , Nitta H , Takahara T , et al. Standardized single-incision plus one-port laparoscopic left lateral sectionectomy: A safe alternative to the conventional procedure[J]. Langenbecks Arch Surg, 2022, 407 (3): 1277- 1284.
13
Chen J , Xu H , Lin S , et al. Robot-assisted pyeloplasty and laparoscopic pyeloplasty in children: A comparison of single-port-plus-one and multiport surgery[J]. Front Pediatr, 2022, 10, 957790.
